Graco Enclosed Wet Cup
Images are representations only.

Enclosed Wet Cup

Brand: Graco, Inc
Request Information

Graco Enclosed Wet Cup
Graco's enclosed wet cup is standard on the 4-ball pump lowers.

The enclosed wet cup minimizes operator interaction resulting in reduced maintenance.
Features
  • Offered as standard configuration in the High-Flo, Viscount and E-Flo pump assemblies.
  • Minimizes operator interaction for reduced maintenance.
  • Maintains consistent lubrication for packings.
  • Spring loaded packings increases the life of throat packings.

Specifications

Brand

Displacement Per Cycle - 3000 cc Lowers

  • 3000 cc

Displacement Per Cycle - 4000 cc Lowers

  • 4000 cc

Displacement Per Cycle - Fluid Inlet & Outlet Sizes

  • See Models in Instruction Manuals.

Displacement Per Cycle - Maximum Fluid Temperature

  • 66° C

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - 1000 cc Lowers

  • 1000 cc

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - 1500 cc Lowers

  • 1500 cc

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - 2000 cc Lowers

  • 2000 cc

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - 750 cc Lowers

  • 750 cc

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - Fluid Inlet & Outlet Sizes

  • See Models in Instruction Manuals.

Displacement Per Cycle (4.75 Inch (12 Cm) Stroke) - Maximum Fluid Temperature

  • 66° C

Maximum Fluid Working Pressure

  • 3.2 MPa, 32 bar

Maximum Fluid Working Pressure - 3000 cc Lowers

  • 3.0 MPa, 30 bar

Maximum Fluid Working Pressure - 4000 cc Lowers

  • 2.3 MPa, 23 bar

Weight - 1000 cc Lowers

  • 19.0 kg

Weight - 1500 cc Lowers

  • 19.5

Weight - 2000 cc Lowers

  • 20.0 kg

Weight - 750 cc Lowers

  • 18.6 kg

Weight - Wetted Parts (Enclosed Wet-Cup)

  • Stainless Steel, Ultra-High Molecular Weight Polyethylene, High-density, Polyethylene, Nylon, Fluoroelastomer

Weight - Wetted Parts (Main Pump)

  • Stainless Steel, PTFE, Leather, Ultra-High Molecular Weight Polyethylene, Tungsten Carbide, Acetal, Carbon Steel (Models 24F420, 24F431, 24F439, 24F447, & 24F423 Only)
