Fiberglass Cutter
Images are representations only.

Fiberglass Cutter

Brand: Graco, Inc
Request Information
Favorite

Fiberglass Cutter Fiberglass Cutter
Graco's high-output fiberglass cutter helps improve uptime.

With its easy-to-change blade cartridges, workers can change blades right on the production line - in a matter of seconds.

The high-output cutter allows you to get the glass output you need with fewer strands of roving. Fewer strands of roving means less chance of tangling, easier handling and more uptime.
Features
  • Easy-to-change blade cartridges keep production moving.
  • Up to 40% lighter than competition for better chopping control.
  • High output cutter provides the output you need with fewer strands of roving.
  • Less roving means less tangling, more uptime.
  • External adjustable anvil tension - no disassembly, no tools required.
  • Speed control lets you adjust glass output on the fly.

Specifications

Brand

Air Inlet Working Pressure - 24E512 & 24P681

  • 5.5-8.6 bar, 0.55-0.86 MPa

Cutter Air Pressure - One Strand

  • 3.4-5 bar, 0.3-0.5 MPa

Cutter Air Pressure - Three Strands

  • 5.5-8.6 bar, 0.6-0.9 MPa

Cutter Air Pressure - Two Strands

  • 5.5-8.6 bar, 0.6-0.9 MPa

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - One Strand

  • 1.7 kg/min

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - One Strand

  • 1.4 kg/min

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - Three Strands

  • 3.2 kg/min

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - Three Strands

  • 4.2 kg/min

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - Two Strands

  • 2.7 kg/min

Cutter Maximum Glass Output at 100 psi (7 bar, 0.7 MPa) - Two Strands

  • 3.3 kg/min

Materials of Construction

  • Aluminum, Stainless Steel, Carbon Steel, Carbide, Chemically Resistant O-Rings

Maximum Air Pressure

  • 8.6 bar, 0.9 MPa

Minimum Air Flow (at 100 psi, 7 bar, 0.7 Mpa) - 24E512 & 24P681

  • 0.47 m³ Per Min

Sound Power Measured Per ISO-3746 - 24E512 & 24P681

  • 111.5 dBA at 100 psig & Max.

Sound Pressure Measured at 3 ft (1 m) from Equipment - 24E512 & 24P681

  • 93.7 dBA at 100 psig & Max.

Sound Pressure Measured at 3 ft (1 m) from Equipment. - 24E512 & 24P681

  • 93.7 dBA at 100 psig & Max.

Weight - 24E512 & 24P681

  • 0.91 kg

Wetted Parts

  • Aluminum, Stainless Steel, Carbon Steel, Carbide, Chemically Resistant O-Rings
